Name: VCE CAT6 RJ45 Pass Through Modular Plugs, 3 Prong Gold Plated Ethernet 50u EZ Crimp Connectors for Solid or Stranded UTP Cable 50-Pack
Brand: VCELINK
SKU: SJ661-50P-US
Price: 17.69 USD
Availability: InStock

VCE CAT6 RJ45 Pass Through Modular Plugs, 3 Prong Gold Plated Ethernet 50u EZ Crimp Connectors for Solid or Stranded UTP Cable 50-Pack

$17.69 CAD$ 25.99 EUR€ 15,99 EUR€ 15,99 EUR€ 15,99 JPY¥ 1399 GBP£ 9.99

Rating:

VCE gold plated RJ45 CAT6 end pass through ethernet RJ45 connector plugs let you quickly and easily create category 6 cables in preferred lengths.

Work effectively with standard cable conductor gauge between 23AWG-26AWG; also works with nearly every style or model of RJ45 crimp tools.

PASS-THRU DESIGN simplifies terminations as wires are inserted through the connector and out the other side. This frustration-free 1-piece plug seats cable jackets tightly for fast crimps and connections.

Transparent gold plated RJ45 plugs allow you to identify wire sequence, eliminating scrap and improper crimps.3-PRONG DESIGN enhances alignment with the conductor.

Package Contents: 10 x RJ45 CAT6 Pass Through Modular Plug Multi-Color. With UL Listed, just use it without concern.

Please allow 4-20 working days for transporting if you purchase here.
Know more atDelivery & Return

VCE Pass-Thru RJ45 CAT6 Modular Data Plug

“VCE Pass Through 8P8C CAT6 Gold Plated Ethernet Connectors” are designed for fast, reliable installations for Category 6 networks.
DIY RJ45 cable connector termination solution for making custom length Ethernet patch cords.

Note:

Suitable for wire OD ∅0.93 ~ ∅1.04, multi-stranded and single-stranded cables 23AWG .
Package Contents: 50pcs x VCE Pass-Thru RJ45 CAT6 Modular Data Plug.

RJ45 8P8C CAT6 Connector

SPECIFICATIONS

ELECTRICAL:

Ul Applications: 250 Volts Ac Max. At 2 Amps.
Dielectric Withstanding Voltage : 1000 Volts Ac. 60 Sec.
Insulation Resistance: 500 MΩ.
Contact Resistance: 20mΩ Max.
Operating Ambient Temperature: -20°c ~ 75°c.

MATERIAL:

Housing: Polycarbonate, Ul94v-0 Or Ul94v-2.
Color: Transparent.
Contact Blade: Copper Alloy.
Gold Plating: 50u.

MECHANICAL:

Strain Relief: 20pound Min.
Durability: 1200 Mating Cycles.


3 Prong Design 3-Prong Blade ensures closer combination between the contacts and the wire core than 2-Prong Blade. 50u gold-plated contacts provide faster speed with less interference.	High Quality Construction Strong mating clip for frequent unplugging. High-Transparency shell allow you to identify wire sequence, eliminate scrap and improper crimps.	Easy to Use You can use them on both solid and stranded cable. Pass-thru design simplifies terminations as wires are inserted through the connector and out the other side.

Pass Through Connector Crimping Tool Suggestions

RJ45 8P8C CAT6 Connector

Use RJ45 Pass Through Crimping Tool will help you crimp the CAT6 EZ Connectors easily, also let you cut the extra wires of your connectors
Please search B07TT5J2WJ, the first crimper from left.
