Mini Single Pon GPON OLT VCELINK

RT008-1P-OL
$499.00 USD
Low Stock <100
QuantityPrice Per Unit / PackSavings
Saves you %

Shipping:

Free Over $39.99 (US&Canada)

Free Over $49.99 (UK&Germany&France)

Free Over $59.99 (Other EU Countries&Mexico)

Free Over $45.99 (Australia)

Know More at Shipping Policy.

Features:

  • 1 x GPON Port, 2 x GE and 1 x 10GE Ports, AC Power
  • Easy Installation and Easy&Plug
  • Centralized and Remote Management
  • Layer 2 Switching Function
  • GPON Function
  • Applies to Small & Medium-sized Enterprises
  • Worldwide Shipping & Fast Delivery
  • 12-month Warranty & Lifetime Product Support

Description

Optical Line Terminal aggregates and manages data from multiple ONTs/ONUs (Optical Network Terminals/Units) at customer premises. VCELINK GPON OLT fully complies with the ITU G.984.x standard and FSAN requirements. The device is equipped with two uplink Ethernet ports, one 10-Gigabit uplink port, and one GPON port. Each GPON port supports a splitting ratio of 1:128. This GPON OLT can be widely used in FTTH, small business applications, and surveillance systems.

Specifications

Product Type Optical Line Terminal
Dimensions 14.17 inch × 7.60 inch × 1.73 inch (360mm × 193mm × 44mm) (L × W × H)
Compliance Standards ITU-T G.984/G.988 standard
Uplink Ports 2× GE / 1× 10GE
PON Port SFP
GPON Port Rate Downstream 2.5Gbps; Upstream 1.25Gbps
Wavelength Forwarding 1490nm; Receiving 1310nm
Interface Type SC/UPC
Fiber Type 9/125μm SMF (Single Mode Fiber)
GPON Max Splitting Ratio 1:128
Transmission Distance Up to 20 km
Management Protocols CLI/WEB/Telnet/SSH/MQTT/OMCI
Layer 2 Features 64k MAC Address, VLAN, IGMP Snooping
Working Temperature -15 ~ 50℃
Storage Temperature -40 ~ 85℃
Ambient Humidity 5 ~ 90% (Non-Condensing)

Features

High-speed Data Transmission

-Supports up to 2.5 Gbps downstream and 1.25 Gbps upstream, enabling fast and reliable internet connection;

-Achieve the farthest transmission distance of 20 km.

Centralized Management

-Supports centralized network management via CLI/WEB/Telnet/SSH/MQTT;

-Also supports alarm, performance, and security management.

-Allows operators to monitor and configure customer ONTs remotely via protocols like OMCI.

Layer 2 Switching

-Supports access, trunk, and hybrid layer two access mode;

-Features VLAN filter functions.

Compact&Cost-Effetive

Mini GPON OLTs are typically used in small-scale deployments like small ISPs, SOHO, small businesses, and other FTTH applications.
