RJ45 Splitter Selector Switch VCELINK
| Quantity | Price Per Unit / Pack | Savings |
|---|---|---|
| 10-49 | $9.50 | 5% |
| 50-99 | $9.00 | 10% |
| 100+ | $8.00 | 20% |
Free Shipping for Orders Over $10.99 in the US.
Fast shipping. Know More at Delivery & Return.
For more information, please send us an inquiry or email us.
Features:
- Can be 1 in and 2 out, or 2 in and 1 out
- Comes With a Switch Button
- Maximum Data Rate: 1000 Mbps
- Supports PoE
- Worldwide Shipping & Fast Delivery
- After-sales Service: 12-month Warranty
Pairs Perfectly With
Description
This is a bi-directional network switch supporting 1-in-2-out and 2-in-1-out transmission. The 2-in-1-out transmission provides a connection between two networks and one device and an easy switch between different networks with physical isolation. The 1-in-2-out mode allows you to connect one Ethernet cable to two different devices and you can switch between different devices without frequent plugging and unplugging. This RJ45 selector box is compatible with Cat5e, Cat5, Cat6, Cat6a, and Cat7, but it can only achieve the maximum data rate of 1000Mbps.
Note: This product does not support the simultaneous use of two networks or allow two devices to access the internet at the same time.
You can contact us directly or email us for more information.
Specifications
| Product Type | RJ45 Selector Switch |
| Size | 2.24 in x 1.58 in x 0.85 in (56.90 mm x 40.13 mm x 21.59 mm) |
| Plastic Shell Material | ABS |
| Housing Material | PBT |
| Metal Shell Material | BRASS, Nickel Plated |
| Printed Circuit Board Material | FR-4 |
| PCB Thickness | 0.06 inch (1.60 mm) |
| Switch Material | ABS |
| Contact Material | Phosphor Bronze Round PIN |
| Contact Area Material | Gold Plated |
| Compatibility | Compatible with RJ45 Connectors (Maximum Network Speed: 1000 Mbps) |
| PoE Capability | Enabled |
| Bandwidth | 100 MHz |
| Shielding Type | BRASS, Nickel Plated |
| Voltage Rating | 125 VAC RMS. |
| Current Rating | 1.5 AMP. |
| Contact Resistance | 100 MILLIOHMS MAX. |
| Insulation Resistance | 1000 MEGOHMS MIN @ 500 VDC |
| Dielectric Strength | 750 VAC RMS 60Hz, 1MIN. |
| C6 Permanent Link | Conform to ANSI/TIA/EIA-568 B.C |
| Modular Plug Standard | Conform to FCC PART 68, SUBPART F. |
| Storage Temperature Range | -40℃ to 80℃(-40 ℉ to 176 ℉) |
| Operating Temperature Range | 0℃ to 70℃ (32℉ to 158℉) |
| Implementation Standards | ANSI/TIA/EIA-568 B.C. |
Features
Versatile Functionality
-Switch Between Networks: The 2-in-1-out configuration enables two networks to connect to a single device and prevent IP serial connection conflicts;
-Switch Between Devices: The 1-in-2-out configuration allows for a seamless switch between different devices without the hassle of unplugging and re-plugging cables.
Enhanced Network Performance
-Supports network speed of up to 1000Mbps at a bandwidth of 100 MHz;
-Supports Power over Ethernet for added functionality;
-Shielded design for stable data transmission.
User-Friendly Design
-The compact size makes this RJ45 splitter selector switch easy to carry and store;
-Features a mechanical slide switch for effortless network toggling with a single finger;
-Supports hot plugging and unplugging for easy use;
-Easy to use with no additional power supply;
-The plug-and-play design allows for a quick connection and disconnection.
Durability&Compatibility
-Built with high-quality ABS housing for long-lasting performance;
-Compatible with all devices with RJ45 ports or connectors;
-Works seamlessly with ADSL, hubs, switches, televisions, routers, computers, etc.
