Outdoor GPON ONU with PoE
Free Shipping for Orders Over $10.99 in the US.
Fast shipping. Know More at Delivery & Return.
For more information, please send us an inquiry or email us.
Features:
- Compliant with ITU-T G.984.x (G.984.5 support)
- Ideal for outdoor or industrial FTTx environment
- 4 IEEE802.3af/at 1000M Ethernet ports
- Bridge mode & router mode selectable
- 6KV surge protection
Pairs Perfectly With
Description
Our Outdoor GPON ONT adheres to the ITU-T G.984.X standard to allow high data transfer rates over fiber optics. Featuring a robust, weatherproof design and 6KV lightning protection, it ensures reliable performance in harsh outdoor environments. With 4 IEEE802.3af/at PoE+ ports, the device simplifies installation and integration into existing networks. It is an ideal device for IP cameras, digital signage, and small cells.
Specifications
| Product Type | Outdoor GPON ONU |
| PON Standard | ITU-TG.984.x Standard - Class B+ |
| Dimensions | 28.5cm x 20cm x 12cm (L x W x H) |
| Weight | 3.5 kg |
| Housing Material | Die-cast Aluminum Housing (Clamshell) |
| Interface | 4 x 10/100/1000BASE-T |
| Power Input | Cable Power 40~90VAC or 110/220VAC, 50/60Hz |
| Operation Temperature | -40°C ~ 60°C |
| Humidity | 5% ~ 100% (non-condensing) |
| Water&Dust Resistance | IP68 |
| Power over Ethernet | PoE and PoE+ with Mode A/B |
| Management | OMCI/WEB/Telnet/SNMP |
Features
Advanced Performance
-Delivers a downstream rate of 2.5 Gbps and an upstream rate of 1.25 Gbps;
-Supports a maximum transmission distance of 20 km;
-2.4 GHz and 5 GHz dual-band support;
-Supports MU-MIMO and multiple intelligent management functions for stable network connectivity.
Durable Construction
-Built with IP68 enclosure to withstand dust and moisture, suitable for extreme environments;
-Provides 6KV surge protection to safeguard the device from power surges.
PoE Support
-Supports IEEE 802.3 af/at standard POE POE+ power supply;
-Remote PoE mode A/B for option.
Wide Applications
Our outdoor GPON ONU is ideal for FTTx deployments, IoT applications, industrial networks, and surveillance and security systems, including IP cameras, digital signage, access points, small cells and more.
